Cone Crusher Wear Parts :
Items: Concave, Mantle, Concave Ring, Concave Segment, Bowl Liner, ConeLiner,Arm Guard, Distribution Plate
Casting Material: Austenstic Manganese Steel (Mn14, M14Cr2, Mn18Cr2,Mn22Cr2)
Casting Method: Water Glass Sand Casting
Applicable Material:Gravel, Granite, Basalt, Ore, Limestone, Sandstone, Quatz,Cobblestone
Applications: Mining, Quarry, Construction,Cement and Materials ,Recycling
CASTEEL Foundry has long understanding and coverage Of Telsmith Gyrasphere spring cone crushers match with following models:
Telsmith Gyrasphere Cone Series:| 24″| 36″Std| 38H| 44″|48″|48FC
| Item Code | Item name | Alternative Number | Model |
| AD0036B407C | Upper Mantle | CAL800096 | 36″Std Gyrasphere |
| AD0036B412C | Lower Mantle | 36″Std Gyrasphere | |
| AD0036B716B | Bowl Liner M | CAL1200537 | 36″Std Gyrasphere |
| AD0036B711B | Concave Ring | CAL800093 | 36″Std Gyrasphere |
| AD0036B710B | Concave Ring Extra Coarse | CAL1500893 | 36″ Gyrasphere |
| AD0036B413B | Lower Mantle | CAL1200535 | 36″ Gyrasphere |
| AD0036B402B | Upper Mantle | CAL1200534 | 36″ Gyrasphere |
| AD0036B212C | Eccentric Bush Inner | 36″Std Gyrasphere | |
| AD0036B211C | Eccentric Bush Outer | 36″Std Gyrasphere | |
| AD0036B406C | Mantle Nut | 36″Std Gyrasphere | |
| AD0036B404C | Mantle Nut Cap | 36″Std Gyrasphere | |
| AC0024B405C | Upper Mantle | CAL1000232 | 24″Gyrasphere |
| AC0024B413B | Lower Mantle | CAL1000231 | 24″Gyrasphere |
| AC0024B702B | Concave Ring | CAL1000229 | 24″Gyrasphere |
| AC0024B211C | Eccentric Bush Inner | 24″Gyrasphere | |
| AC0024B210C | Eccentric Bush Outer | 24″Gyrasphere | |
| AC0024B403C | Mantle Nut | 24″Gyrasphere | |
| AC0024B404C | Mantle Stud Cap | 24″Gyrasphere | |
| AF0038B409A | Mantle | 38H Gyrasphere | |
| AF0038B703A | Bowl Liner | 38H Gyrasphere | |
| AF0044B212A | Eccentric Bush Inner | 38H Gyrasphere | |
| AF0038B222A | Eccentric Bush Outer | 38H Gyrasphere | |
| AFO038B406A | Shaft Nut | 38H Gyrasphere | |
| AE1110B410A | Burning Ring | 38H Gyrasphere | |
| AF0038B404A | Main Shaft Nut Cap | 38H Gyrasphere | |
| AF0044B410A | Mantle | CAL1000363 | 44″ Gyrasphere |
| AF0044B706A | Bowl Liner | CAL1000364 | 44″ Gyrasphere |
| AF0044B212A | Eccentric Bush Inner | 44″ Gyrasphere | |
| AF0044B222A | Eccentric Bush Outer | 44″ Gyrasphere | |
| AFO044B407A | Shaft Nut | 44″ Gyrasphere | |
| AE1110B410A | Burning Ring | 44″ Gyrasphere | |
| AD0048B437B | CAL1200576 | 48FC Gyrasphere | |
| AD0048B418B | CAL1200587 | 48FC Gyrasphere | |
| B272-312 | Concave Ring | Pegson Telsmith | SBS 48FC |
| D-272-307 | Lower Mantle | Pegson Telsmith | SBS 48FC |
| E-272-308 | Upper Mantle | Pegson Telsmith | SBS 48FC |
