Jaw Crusher Wear Parts :
Item Names: Jaw Plates,Stationary Jaw Tooth, Movable Jaw Die Fixed Jaw, Swing Jaw Plate,
Jaw Fixed, Jaw Moveable ,Cheek Plate ,Side Plate,Jawface Fixed,Crusher Jaw Loose
Casting Material: Austenstic Manganese Steel (Mn14, M14Cr2,Mn18Cr2, Mn22Cr2)
Casting Method: Water Glass Sand Casting
Applicable Material:Gravel, Granite, Basalt, Ore, Limestone,Sandstone ,Quatz,Cobblestone
Applications: Mining , Quarry, Construction ,Cement and Materials,Recycling
CASTEEL Foundry has long understanding and coverage of Goowin Barsby H-BAG and Wickers Jaws match with following Models
Goodwin Series 5 Jaws : 30″x18″|42″x24″ |42″x30″ |36″x6″ Granulator
MFL Mobile Crusher: STE90-60 | STE 108-75|RCI 100-100 |RCI 100-130
Krupp Jaw Range: ERC18-14 |EB12-10 |EB14-11 |EB16-12|EB20-15
Wickers Jaw Range:
| Item Code | Item name | Model |
| A4679/18 LH | Crusher Feed Chute | KK30*18 |
| Fixed Jaw Reversible | KK30*18 | |
| Swing Jaw Reversible | KK30*18 | |
| ST044A | Toggle Plate | KK30*18 |
| B7775 – 03 ST054 3018 | Lower Cheek Plate LH | KK30*18 |
| STO333018 | Swing Jaw Keeper Plate | KK30*18 |
| ST053 3018 | Upper Cheek Plate LH | KK30*18 |
| ST034 3018 | Fixed Jaw Keeper Plate | KK30*18 |
| Jaw Plate- Swing/Static Jaw | KK34 | |
| J094 34 35 | Pitman | KK34 |
| S6476-77 | Wearing Plate | KK35 |
| Toggle Plate | KK42*26 | |
| ST404226-30 | Toggle Seat | KK42*26 |
| ST434226-30 | Toggle Seat | KK42*26 |
| STO33.4226 | Keeper Plate | KK42*26 |
| STO34.4226 | Keeper Plate | KK42*26 |
| B7728 | Liner LH | KK42*30 |
| Toggle Plate | KK42*30 | |
| STO 33A4230 | Wedge – Swing & Fixed Keeper Plates | KK42*30 |
| STO3A-4230 | Jaw Plate | KK42*30 |
| STO31A 4230 | Swing Jaw | KK42*30 |
| CC102233_F | Upper Liner | KK42*30 Minu |
| CC102453_F | Lower Liner | KK42*30 Minu |
| 100653RECW5001 | Jaw Plate | KK53 |
| J009-54 | Toggle Plate | KK54 |
| J00654422 | Jaw Plate | KK54 |
| SK1864 B5090 | Cheek Plate | KK56 |
| PATT. NO. 2040 | Jaw Plate N/R 10 Tooth | KK56 |
| PATT. NO. 2039 | Jaw Plate N/R 9 Tooth | KK56 |
| J006 562040 | Jaw Plate Plain N/R B3853 | KK56 |
| SK2741 C6257 | Lower Cheek Plate | KK57 |
| J094-54-57 | Pitman C4815 Patt 1063 | KK57 |
| SK2741 ITEM 77L | Upper Wearing Plate LH | KK57 |
| J00671REA9982 | Jaw Plate | KK67 |
| J00671R 4479B5147 | Resible Jaw Plate | KK71 |
| J095 71-73 RE | FRONT TOGGLE | KK73 |
| Ex4058 | Jaw | KK75S |
| Pitman | KK75S | |
| J096 75S | Rear Toogle | KK75S |
| J095 75S | Front Toggle | KK75S |
| J076 54-56 | Cheek Plate | KK75S |
| PATT 1328 | Jaw Plate Non Rev | KK75S |
| BL SK2274 | Cheek Plate | KK80 |
| J006-80 3486 | 17 Toothed Rev Jaw | KK80 |
| J006-80 3485 | 18 Toothed Rev Jaw | KK80 |
| J006 953550 B3646 | Swing Jaw | KK95 |
| J006 95A9994 SK1311 | Fixed Jaw | KK95 |
| J094 79-95 | PitmanB3233 PATT 1118 | KK95 |
| J096 79-95 | Pitman | KK95 |
| J096 79-95 | Pitman | KK95 |
| SK1920 | Bottom Cheek Plate | KK95 |
| J006 95A9993 | Jaw Plate Non-Reversible | KK95 |
| J076-95 | Middle Cheek Plate | KK95 |
| BL SK2761 | Cheek Plate | KK101 |
| J006-101RE | Jaw Plate | KK101 |
| B5338-77 | Wear Plate LH | KK106 |
| B5338-76 | Cheek Plate Lower LH | KK108 |
| Middle Cheek Plate | KK114 | |
| Bottom Cheek Plate | KK114 | |
| Top Wear Plate LH | KK114 | |
| B0229 | KK114 | |
| B0355 | Jaw Plate 0 Pitches | KK114 |
| B0230 | Toothed Jaw Plate Non Rev | KK114 |
| B0356 | Reversible Toothed Jaw Plate | KK114 |
| C3332 | Front Toggle | KK120 |
| C3331 | Rear Toogle | KK120 |
| Pitman ITEM 94 | KK120 | |
| J097 101-120 | Toggle Pin | KK120 |
| BL SK2534 | Cheek Plate | KK120 |
| A6690 | Grid Bar | KK120 |
| Jaw Plate | KK120 | |
| J006-120-4698 | Jaw Plate Non Rev Tooth | KK120 |
| Reversible Toothed Jaw Plate | KK120 | |
| J071 114-120 B7669 | Bumper Plate | KK120 |
| Rev Plain Jaw Plate | KK120 | |
| F2-2 | Grizzly Deck Rear | KK120 |
| Lower Jaw Plate | KK150 | |
| Jaw Plate Upper | KK150 | |
| Jaw Plate Upper | KK150 | |
| J096A 150-160 | Pitman | KK160 |
| J088 150-160 | Toggle Seat -MD10554 PATT 3988 | KK160 |
| Corrugated Lower Jaw | KK160 | |
| B7526 | Corrugated Lower Jaw | KK160 |
| Corrugated Fixed Jaw Upper | KK160 | |
| Corrugated Swing Jaw Upper | KK160 | |
| Sk2231 | Middle Cheek Plate | KK160 |
| BL SK1938 | Lower Cheek Plate | KK200 |
| Lower Cheek Plate | KK200 | |
| 1041 Lower Jaw Plate 1041 | KK200 | |
| 1040 Upper Jaw Plate 1040 | KK200 | |
| BL SK1938 | Cheek Plate | KK200 |
