VSI Crusher Wear Parts :
Item Names: Blow Bar,Blow Hammer, Impactor Hammer,Impator Bar,Impactor Liner
Impact plate, Curtain Liner, Breaker Plate, Apron liner,Scale Board,Grinding Bar, Kickback Plate
HSI Crusher Parts, Square steel,Liner Plates,Side Liner, Impact Rack,Grinding Path
Casting Material: Chormium Cast Iron, Martensite Alloy Steel, CeramicInserts
Casting Method: Water Glass Sand Casting, Lost Foam Casting
Applicable Material:Gravell Granite Basalt| Ore| Limestonel Sandstone|Quatz|cobblestone
Applications: Quarry,Construction,Cement, Asphalt & Concrete Aggregates Recycling & Shaping
CASTEEL Foundry has long understanding and coverage Of CV vertical shaft impact crushers match with following models::
VSI Series CV228| CV229|CV215|CV217|CV218
| Item Code | Item name | Description | Model |
| 488.1801-901 | VSI TURBO TIP HARD SET | VSI Liner | 通用 |
| 488.0368-901 | BACK UP TIP SET | VSI Liner | CV215 |
| 488.1118-901 | TRAIL PLATE SET | VSI Liner | CV215 |
| 488.1565-901 | TURBO CAVITY WEAR PART SET (LOWER) | VSI Liner | CV215 |
| 488.1662-901 | TURBO CAVITY WEAR PART SET (UPPER) | VSI Liner | CV217 |
| 488.1459-901 | TURBO TIP SET | VSI Liner | CV217 |
| 488.0365-901 | TRAIL PLATE SET | VSI Liner | CV215、CV217 |
| 488.085-901 | UPPER WEARPLATE SET | VSI Liner | CV215、CV217 |
| 488.0851-901 | LOWER WEARPLATE SET | VSI Liner | CV218、CV228、CV229 |
| 488.1456-901 | TURBO TIP SET | VSI Liner | CV218、CV228、CV229 |
| 488.1457-901 | TURBO TIP SET | VSI Liner | CV218、CV228、CV229 |
| 488.0362-901 | TRAIL PLATE SET | VSI Liner | CV218、CV228、CV229 |
| 488.0360-901 | UPPER WEARPLATE SET | VSI Liner | CV218、CV228、CV229 |
| 488.0361-901 | LOWER WEARPLATE SET | VSI Liner | CV218、CV228、CV229 |
| 488.1644-901 | TURBO CAVITY WEAR PART SET (UPPER) | VSI Liner | CV218、CV228、CV229 |
| 488.1703-901 | CAVITY WEARPLATE SET（MIDDLE） | VSI Liner | CV218、CV228、CV229 |
| 488.1704-901 | TURBO CAVITY WEAR PART SET (LOWER) | VSI Liner | 通用 |
| 488.1513-901 | DISTRIBUTER LOCATING PIN SET | VSI Liner | CV215、CV217 |
| 488.0853-901 | TOP WEAR PLATE SET | VSI Liner | CV217 |
| 488.0690-901 | VSI Liner | CV218、CV228、CV229 | |
| 488.0369-901 | TOP WEAR PLATE SET | VSI Liner | CV218、CV228、CV229 |
| 488.0076-901 | DISTRIBUTER PLATE | VSI Liner | CV215 |
| 488.077-901 | DISTRIBUTER PLATE | VSI Liner | CV217 |
| 488.1123-901 | DISTRIBUTER PLATE | VSI Liner | CV218、CV228、CV229 |
| 488.0258-901 | FEED TUBE | VSI Liner | CV215、CV217 |
| 485.0091-901 | FEED TUBE | VSI Liner | CV218、CV228、CV229 |
| 488.0841-901 | TOP PLATE | VSI Liner | CV215、CV217 |
| 488.0769-901 | TOP PLATE | VSI Liner | 通用 |
| 840.0067-901 | SCREW M6S 16X45 8.8 ISO 4017 | VSI Liner | 通用 |
| 841.0502-901 | SCREW M6S 24×60 12.9 | VSI Liner | 通用 |
| 840.0077-901 | SCREW M6S 20×50 8.8 ISO 4017 | VSI Liner | 通用 |
| 845.0009-901 | Nut M6M M16 8 FZB ISO 4032 | VSI Liner | 通用 |
| 840.0069-901 | Screw M6S M16x55 8.8 ZP Pt. | VSI Liner | |
| 488.0315-001 | GUSSET WEAR CASTING | VSI Liner | |
| 488.0694-901 | VSI Liner | ||
| 488.1458-901 | VSI Liner | ||
| 488.0793-001 | TAPER LOCK. | VSI Liner | |
| 488.0364-901 | VSI Liner | ||
| 488.0156-001 | Wear ring | VSI Liner |
